Features & Benefits:
- Higher luminance (1) from 18,000cd.m2 to 70,000 cd/m2 Less than 20% luminance loss after 100.000 hours (3)
- From ≥20.000 cd/m2
- Less than 20% luminance loss after 100.000 hours (3)
- Better uniformity (1) ≥95% (±10%) (2) With the shortest chromaticity shift. Less than 10% after 100,000hours (3)
- Expected life > 100.000 hours
- Ultra slim housing 8.5mm/0.334″ (2)
Specifications:
- (1) Continuous mode
- (2) On standard size
- (3) Room temperature = 20°C
Available Sizes:
- Standard sizes (mm): 50×50
- Standard sizes (inches): 1.97×1.97
- Custom sizes: All sizes possible up to: 500mm/19.685″ (subject to minimum quantities)
Additional Standard Sizes:
- Standard sizes (mm): 20×20, 50×50, 100×100, 200×200, 150×40, 160×120, 300×220, 400×200
- Standard sizes (inches): 0.79×0.79″, 1.97×1.97″, 3.94×3.94″, 7.87×7.87″, 5.91×1.57″, 6.29×4.72″, 11.81×8.66″, 15.75×7.87
- Custom sizes: All sizes possible up to: 500mm/19.685″
Included with Each PHLOX® Backlight:
- Certificate of uniformity and luminance
- Seal of quality on the back
- 12 months warranty
