Features & Benefits:
- Resolutions from 0.5MP to 127.7 MP
- Frame rates up to 1594 fps
- 25 GigE SPF28 interface (25x GigE speeds)
Specification & Models:
| Model | Resolution | Frame Rate | Sensor Name | Pixel Size |
|---|---|---|---|---|
| HB-500-S-C | 0.5MP | 1594.7fps | Sony IMX426 | 9×9µm |
| HB-1800-S-C | 1.76MP | 662.1fps | Sony IMX425 | 9×9µm |
| HB-2000-S-C | 2.01MP | 477.6fps | Sony IMX422 | 4.5×4.5µm |
| HB-2800-S-C | 2.8MP | 409.2fps | Sony IMX421 | 4.5×4.5µm |
| HB-5000-G-C | 5.61MP | 290fps | Gpixel GMAX2505 | 2.5×2.5µm |
| HB-5000-SB-C | 5.1MP | 269fps | Sony S IMX537 | 2.74×2.74μm |
| HB-7000-S-C | 7.06MP | 207.1fps | Sony IMX420 | 4.5×4.5µm |
| HB-8000-SB-C | 8.1MP | 201fps | Sony S IMX536 | 2.74×2.74μm |
| HB-9000-G-C | 9.07MP | 290fps | Gpixel GMAX2509 | 2.5×2.5µm |
| HB-12000-C | 12MP | 188fps | AMS CMV12000 | 5.5×5.5µm |
| HB-12000-SB-C | 12.4MP | 192fps | Sony S IMX535 | 2.74×2.74μm |
| HB-16000-SB-C | 16.13MP | 145fps | Sony S IMX532 | 2.74×2.74μm |
| HB-17000-S-C | 16.8MP | 61fps | Sony IMX387 | 3.45×3.45µm |
| HB-18000-G-C | 18.5MP | 125fps | Gpixel GMAX2518 | 2.5×2.5µm |
| HB-20000-S-C | 19.5MP | 43fps | Sony IMX367 | 3.45×3.45µm |
| HB-20000-SB-C | 20.28MP | 100fps | Sony S IMX531 | 2.74×2.74μm |
| HB-25000-G-C | 26.21MP | 75fps | Gpixel GMAX0505 | 2.5×2.5µm |
| HB-25000-SB-C | 24.47MP | 98fps | Sony S IMX530 | 2.74×2.74μm |
| HB-30000-S-C | 31.36MP | 35.4fps | Sony IMX342 | 3.45×3.45µm |
| HB-50000-C | 50MP | 30fps | AMS CMV50000 | 4.6×4.6µm |
| HB-65000-G-C | 65MP | 35fps | Gpixel GMAX3265 | 3.2×3.2µm |
| HB-127-S-C | 127.7MP | 17fps | Sony IMX661 | 3.45×3.45µm |
