DBK 33UX174.AS Colour 2.3 MP (1,920 x 1,200), 60 fps, Sony IMX174LQ Sensor, without IR cut filter, USB 3.0
The camera ships with IC Capture.AS, a comprehensive software package with which you can capture lossless and uncompressed images sequences and write them to disk as AVI files, or as a series of singular bitmaps.
Features & Benefits:
- 1/1.2 ” CMOS Pregius, Sony IMX174LQ (progressive scan).
- Resolution 1920 x 1200 pixels (2.3 MP).
- Up to 60 FPS and 30 seconds exposure.
- C mount.
- Software included.
Color Interpolation
- For visualization applications, the RAW image stream from the CMOS Pregius chip must be interpolated before viewing or saving in common formats.
- IC Capture.AS performs color interpolation, reducing the load on the DBK 33UX174.AS’s processor.
- You can select the option in IC Capture.AS for the camera to perform color interpolation, allowing data transfer to reach the camera’s maximum of 60 FPS.
- If color interpolation is not required, it can be turned off, and the image stream is saved in RAW format.
Sony IMX174LQ 1/1.2″ CMOS Pregius Chip
- The DBK 33UX174.AS features the color Sony IMX174LQ progressive scan CMOS Pregius chip.
- 1/1.2″ format producing a resolution of 1920 x 1200 pixels.
- High-quality performance makes it suitable for scientific, industrial, and medical image processing applications.
No Compression, No IR Cut Filter
- The DBK 33UX174.AS outputs a non-compressed video stream directly via the USB 3.0 connector.
- The camera lacks an IR cut filter, color filter, or other electronic filters, making it ideal for capturing true-to-life images of the night sky.
High Speed Data Transfer Via USB 3.0
- Fast USB 3.0 connector for transferring the vast data generated by the stream of uncompressed and lossless color images.
Included Software
- Includes device driver and camera control/image acquisition application IC Capture.AS.
- Compatible with Windows 10, 7, Vista, and XP (32 and 64 bit).
- Software for Mac OS and Linux available from third parties.
Specifications:
- General Behavior
- Video output format: 8-Bit Bayer (RG), 16-Bit Bayer (RG), YUV 4:2:2, YUV 4:1:1, RGB24
- Dynamic range: 8/12 bit
- Optical Interface
- IR cut filter: no
- CMOS STARVIS specification: IMX174LQ
- Type: progressive scan
- Format: 1/1.2″
- Resolution: H: 1920 pixels, V: 1200 pixels (2.3 MP)
- Lens mount: C mount
- Electrical Interface
- Connector type: USB 3.0
- Supply voltage: 4.5 VDC to 5.5 VDC (via USB 3.0 cable)
- Current consumption: approx. 250 mA at 5 VDC
- Mechanical Interface
- Dimensions: H: 29 mm, W: 29 mm, L: 43 mm
- Mass: 65 g
- Manual Adjustments
- Shutter (exposure time): 1/50,000 to 30 seconds
- Gain: 0 dB to 48 dB
- Environmental
- Max. temperature (operation): -5 °C to 45 °C
- Max. temperature (storage): -20 °C to 60 °C
- Max. humidity (operation): 20 % to 80 % non-condensing
- Max. humidity (storage): 20 % to 95 % non-condensing
