Features & Benefits:
- Ultra-high resolution lens, suitable for 1″ 20MP Sensor (IMX183/IMX255(267)/IMX535(545))
- Super low distortion design, High versatility lens for any industrial applications
- Higher relative illuminance makes edge images sharp & clear
- Floating design achieves ultra-high resolution from Near to Far.
- Vibration resistance up to 5G, Compact design
- 1″ sensor size.
- Available in 8, 12, 16, 25, 35, 50 and 75mm focal lengths
Specification & Models:
| Model Name | Focal Length | F-Number | Working Distance | Distortion | Weight |
|---|---|---|---|---|---|
| V0826-MPZ | 8mm | 2.6 | 0.1m – Inf. | -0.8%(y=8.0) | 203.1g |
| V1226-MPZ | 12mm | 2.6 | 0.1m – Inf. | 0.0%(y=8.0) | 98.4g |
| V1624-MPZ | 16mm | 2.4 | 0.1m – Inf. | 0.0%(y=8.0) | 108.1g |
| V2520-MPZ | 25mm | 2 | 0.15m – Inf. | 0.0%(y=8.0) | 73.1g |
| V3522-MPZ | 35mm | 2.2 | 0.2m – Inf. | 0.0%(y=8.0) | 118.2g |
| V5024-MPZ | 50mm | 2.4 | 0.2m – Inf. | 0.0%(y=8.0) | 138.5g |
| V7531-MPZ | 75mm | 3.1 | 0.25m – Inf. | 0.0%(y=8.0) | 176.1g |
